Low-Pressure Gas Alarm System with Display – 8 Channel
HSN Code: 85311090
The Chromgate Low-Pressure Gas Alarm System with Display is designed for continuous monitoring of gas-line pressure and provides an audible and visual alarm when the pressure in any monitored gas line falls below the preset limit. The system supports monitoring of up to 8 independent gas channels, making it suitable for laboratories, pharmaceutical facilities, chemical industries, research institutions, and centralized gas distribution systems.
The system is provided with a clear digital display for convenient monitoring of individual channel status and pressure conditions. Pressure Sensors and Shielded Cables are to be procured separately according to the required gas service, pressure range, installation requirements, and cable length.
Gas Compatibility: Available for use with Nitrogen (N₂), Hydrogen (H₂), Zero Air (ZA), Helium (He), Oxygen (O₂), Argon (Ar), Carbon Dioxide (CO₂), Acetylene (C₂H₂), Nitrous Oxide (N₂O), Ammonia (NH₃) and other laboratory and industrial gases.
Features & Technical Specifications:-
- Product Type: Low-Pressure Gas Alarm & Monitoring System
- Configuration: 8-Channel
- Monitoring Channels: Up to 8 independent gas pressure channels
- Display: Digital display for monitoring channel-wise pressure/status
- Alarm Function: Provides audible and visual indication when the monitored gas pressure falls below the preset alarm threshold.
- Alarm Set Point: Adjustable / programmable as per application requirements.
- Alarm Indication: Individual channel-wise alarm indication for easy identification of the affected gas line.
- Alarm Type: Visual and audible alarm.
- Pressure Sensor: 08 Nos. pressure sensors, to be procured separately.
- Sensor Compatibility: Pressure sensors selected according to the required gas type, pressure range, connection, and application.
- Shielded Cable: Required shielded cables for sensor connection, to be procured separately.
- Sensor Input: Suitable inputs for up to 8 pressure sensors.
- Channel Identification: Individual channel identification for monitoring different gas lines.
- Control Panel: Compact panel-mounted control unit suitable for wall or suitable enclosure mounting.
- Power Supply: 230VAC ±10%, 50 Hz.
- Electrical Protection: Suitable internal protection for reliable operation under specified electrical conditions.
- Alarm Reset: Manual / automatic reset, as applicable to the selected configuration.
- Output: Alarm indication and status display; additional alarm output/contact can be provided as required.
- Enclosure: Robust enclosure suitable for laboratory and industrial installation.
- Installation: Suitable for wall mounting or panel installation.
- Operation: Continuous monitoring of connected gas-line pressure.
- Application: Low-pressure monitoring of centralized gas distribution and supply systems.
